    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier

    Ask Lasest Price
    Brand Name : PK
    Model Number : XZS1800
    Certification : CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1000SETS/MONTH
    Delivery Time : 10-15DAYS
    • Product Details
    • Company Profile

    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier

    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier


    Introduction

    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier is used in a large range of industry, such as:

    1. Chemical industry: resin, paint, industrial drugs, cosmetics, paint, herbal powder and so on.

    2. Food industry: sugar powder, starch, salt, rice powder, milk powder, soybean milk, egg powder, soy sauce, juice, etc.

    3. Metals, metallurgy and mining: aluminum powder, lead powder, copper powder, ore, alloy powder, welding rod4. powder, manganese dioxide, electrolytic copper powder, Electromagnetic material, grinding powder, refractory materials, kaolin, lime, alumina, heavy calcium carbonate, quartz sand, etc.

    5. Other industries: waste oil, waste water, dyeing and finishing waste water, paper making, additives, activated carbon.


    Working Principle
    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier is produced by eccentric weights on the upper and lower ends of the motion-generator shaft. The direction of the eccentric weights can change its rotational mode,rotation of the upper weight creates vibration in the horizontal plane, which causes material to move across the screen cloth to the periphery,while the lower weight acts to tilt the machine, causing vibration in the vertical and tangential planes.
    Stainless Steel Food Processing Starch Sieving Machine Rotary Sieve Classifier

    Advantages and Features

    1. Reasonable and scientific package scheme is provided before shipping to save cost

    2. Customized solution is provided for individual demand

    3. Small volume, light weight, convenient to move, simple operation,smooth running

    4. Discharging mouth can be adjusted to any direction to fit your project

    5. Specialized net rack design,easy to take down the screen cloth for cleaning

    6. Similar with Rotex screener,but the cost is pretty competitive and favorable

    7. Construction material of bouncing balls with rubber or silica gel are optional

    8. Screens with different construction materials are available in different applications

    9. Multi layers can be customized as per different sieving requirement


    Technical Parameters

    ModelNominal Diameter(mm)Screen Diameter(mm)Screen Surface Area(m3)Feeding size (mm)SpecificationNO. of LayersFrequency(rpm)Power(Kw)
    XZ-4004003400.09<102-3251-515000.18
    XZ-6006005300.22<100.25
    XZ-8008007200.4<200.55
    XZ-100010009000.63<200.75
    XZ-1200120011000.95<201.1
    XZ-1500150014001.5<201.5
    XZ-1800180017102.3<302.2
    XZ-2000200019102.86<303.7


    Note: the parameter above is just for reference,it can be customized by different requirment.



    Selection Conditions

    ♦Material to be processed: _____♦Max. granule size of the feeding material: _____mm
    ♦Handling capacity (Ps. It means the total♦Layer number: ______
    material capacity feeding from the inlet): _____t/h♦Mesh size of each layer: _____mm
    ♦Bulk Density: _____t/m3♦Particle distribution percentage:____________
    ♦Material temperature: _____ºC;(please check the following example to help you
    ♦water content:____%understand it.Supposing the layer number is 2
    ♦Material is corrosive or not: ____ (Ps. Yes or No)and the aperture size of each layer is 10mm and 5mm,
    ♦Material is sticky or not: ____ (Ps. Yes or No)then you will get 3 kinds of products: X,Y and Z.
    ♦Working environment is indoor or outdoor: _____X≥10mm; 5mm≤ Y < 10mm; Z<5mm.
    ♦Working environment temperature: ______ ºCWe want to confirm the following information:
    ♦Upstream equipment (Ps. It means what kind of1)The percentage of X in the whole material:_____%;
    equipment is used to feed the material): _____2)The percentage of Y in the whole material:_____%;
    ♦Downstream equipment (Ps. It means what kind of3)The percentage of Z in the whole material:_____%;)
    equipment is used to discharge the material): _____♦Working power supply: _____V ______HZ
