    Shredded Tires Rice Husk Handling Incline Chevron Belt Conveyor For MSW

    Ask Lasest Price
    Brand Name : PK
    Model Number : DTIIA
    Certification : CE Certificate,ISO14001:2015, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 600SETS/YEAR
    Delivery Time : ABOUT 35 DAYS
    • Product Details
    • Company Profile

    Shredded Tires Rice Husk Handling Incline Chevron Belt Conveyor For MSW

    Shredded Tires Rice Husk Handling Incline Chevron Belt Conveyor For MSW


    Introduction

    DT belt conveyor is a revamp product in place of that of TD75 and DX, which has been taken into use since 1994. DT Fixing conveyor belt Model DT is a kind of general products, which could be widely used on each line such as metallurgy, mine, coal, port, power station, building material, chemical industry, light industry and petroleum etc. Transportation system combined with single or several machines is used to transport various loose materials and finished products with density 500-2500KG/m3
    Belt width series (mm), 500, 650, 800, 1000, 1200, 1400, 1600, 1800, 2000, 2200, 2400.


    Advantages and Features

    1. The range of conveyed materials is widely. Wet, dry, powder, block materials and packaged product are can be used belt conveyor;
    2.The capacity is large, the convey distance is length;
    3.Multiple spot feeding and discharge can be realized in one belt conveyor;
    4. Continue operation, running steady and small noise;

    5. Simple structure, work reliable, easy operation, installation and maintenance.



    Technical datas:

    Roller formRunning speed(m/s)Belt width (mm)
    500650800100012001400
    capacity(m3/h)
    Trough roller0.878130--------
    1.097164278435655891
    1.251222063485448211115
    1.615626444569610481427
    2.019132354685312841748
    2.5232391664103315562118
    3.15----824123318582528
    4.0--------22022996
    Falt roller0.84167118------
    1.05288147230345469
    1.2566110184288432588
    1.684142236368558753
    2.0103174289451677922
    2.51252113505468211117


    Selection Conditions


    ♦ Material to be processed:


    ♦ Installation angle:

    ___°(if the installation is inclined)

    ♦ Bulk density:

    t/m3

    ♦ Lifting height:

    ___m (if there is slope angle)

    ♦ Water content:

    %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature:

    °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material:

    mm

    ♦ Working environment:

    (indoor or outdoor)

    ♦ Max. Granule size:

    mm

    ♦ Working environment temperature:

    °C

    ♦ Handling capacity:

    t/h

    ♦ Working power supply:

    3 Phase V Hz

    ♦ Conveying length:

    m

    ♦ Quantity:

    sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
