    Industrial Belt Conveyor Machine Long Distance for Bulk Material Handling

    Ask Lasest Price
    Brand Name : PK
    Model Number : DTIIA
    Certification : CE Certificate,ISO14001:2015, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 600SETS/YEAR
    Delivery Time : ABOUT 35 DAYS
    • Product Details
    • Company Profile

    Industrial Belt Conveyor Machine Long Distance for Bulk Material Handling

    Industrial Belt Conveyor Machine Long Distance for Bulk Material Handling


    Introduction

    Belt conveyor is composed by two endpoint pulleys and a closed conveyor belt. The pulley that drives conveyor belt rotating is called drive pulley or transmission drum; the other one-only used to change conveyor belt movement direction-is called bend pulley. Drive pulley is driven by the motor through reducer, and conveyor belt dragging relies on the friction drag between the drive pulley and the conveyor belt. The drive pulleys are generally installed at the discharge end in order to increase traction and be easy to drag. Material is fed on the feed-side and landed on the rotating conveyor belt, then rely on the conveyor belt friction to be delivered to discharge end.


    Advantages and Features

    1. Belt conveyors can be loaded and unloaded at any point according to the production process.
    2. Can be customized, suitable for conveying various materials in the Long distance.
    3. Conveyor length can be customized according to your need.
    4. Belt conveyor cleaner can be installed to clean the conveyor belt.
    5. Conveyor rollers are manufactured by our roller production line to ensure smooth conveyor system.



    Technical datas:

    Roller formRunning speed(m/s)Belt width (mm)
    500650800100012001400
    capacity(m3/h)
    Trough roller0.878130--------
    1.097164278435655891
    1.251222063485448211115
    1.615626444569610481427
    2.019132354685312841748
    2.5232391664103315562118
    3.15----824123318582528
    4.0--------22022996
    Falt roller0.84167118------
    1.05288147230345469
    1.2566110184288432588
    1.684142236368558753
    2.0103174289451677922
    2.51252113505468211117


    Selection Conditions


    ♦ Material to be processed:


    ♦ Installation angle:

    ___°(if the installation is inclined)

    ♦ Bulk density:

    t/m3

    ♦ Lifting height:

    ___m (if there is slope angle)

    ♦ Water content:

    %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature:

    °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material:

    mm

    ♦ Working environment:

    (indoor or outdoor)

    ♦ Max. Granule size:

    mm

    ♦ Working environment temperature:

    °C

    ♦ Handling capacity:

    t/h

    ♦ Working power supply:

    3 Phase V Hz

    ♦ Conveying length:

    m

    ♦ Quantity:

    sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
