    Powder Fly Ash Feeding Tubular Sand Concrete Auger Horizontal Cement Screw Conveyor

    Ask Lasest Price
    Brand Name : PK
    Model Number : GX
    Certification : CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1000SETS/YEAR
    Delivery Time : ABOUT 30 DAYS
    • Product Details
    • Company Profile

    Powder Fly Ash Feeding Tubular Sand Concrete Auger Horizontal Cement Screw Conveyor

    Powder Fly Ash Feeding Tubular Sand Concrete Automatic Inclined Auger Horizontal Cement Screw Conveyor


    Introduction

    Powder fly ash feeding tubular sand concrete automatic inclined auger horizontal stainless steel small cement screw conveyor(also known as auger conveyor, screw conveyor, and spiral conveyor), is the main unit for mechanical transport operation of industry and agriculture, which uses motor to drive screw rotation and move material to achieve conveying purpose. Pipe screw conveyor is suitable for all industries such as building material, chemical industry, power industry, metallurgy, coal industry and grain industry, for horizontal or tilted transportation for powdery, granular and small lump materials, such as coal, dust, residue, cement and grain which their temperature is less than 200℃.



    Advantages and Features
    1. Whole sealing structure, no pollution to the environment,no material leakage.
    2. According to working conditions, screw conveyor can be designed to multiple inlets and outlets.
    3. Flexible installation type, conveyor angle can be 0-30 degree to meet varies requirement.
    4. Hanging bearing is provided to connect screw blades and bear the screw body weights.
    5. Adopts the method of spot welding to weld spiral blade on the screw shaft.
    6. Construction material with carbon steel, stainless steel and abrasion-resistant alloys are optional.
    7. Can be disassemble into several sections, save space during transportation.
    8. Reducer motor brand can be domestic or imported: Tailong, , Siemens etc.

    GX Screw Conveyor Technical Performance
    TypeLength/mThrough put (t/h)Rotating speed/(r/min)ReducerMotorWeight/kg
    TypeSpeed ratioTypePower/kW
    GX20010960YZQ25023.34Y90S-41.1726
    GX20020960YZQ25023.34Y90L-41.51258
    GX2501015.660YZQ25023.34Y100L1-42.2960
    GX2502015.660YZQ25023.34Y100L1-431750
    GX3001021.260YZQ35023.34Y100L2-431373
    GX3002021.260YZQ35023.34Y112M-442346
    GX400105160YZQ40023.34Y132S-45.51911
    GX400205160YZQ50023.34Y160M-4112049
    GX5001087.560YZQ40023.34Y132M7.52381
    GX5002087.560YZQ65023.34Y180M-418.55389
    GX60010134.245YZQ75023.34Y180L-4223880
    GX60010134.245YZQ85023.34Y250M-4557090


    Selection Conditions


    ♦ Material to be processed:_

    ♦ Installation angle:___° (if the installation is inclined)

    ♦ Bulk density: t/m3

    ♦ lifting height:__m (if there is slope angle)

    ♦ Water content: %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature: °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material: mm

    ♦ Working environment: (indoor or outdoor)

    ♦ Max. Granule size: mm

    ♦ Working environment temperature: °C

    ♦ Handling capacity: t/h

    ♦ Working power supply: 3 Phase V Hz

    ♦ Conveying length (distance between inlet and outlet): m

    ♦ Quantity: sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
